Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    82
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Displacement (cc):
    976
  • Horsepower RPM:
    7000
  • Torque (Ft Lbs):
    69
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Dual Hydraulic Disc
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    64
  • Height (in):
    82
  • Wheelbase (in):
    83
  • Ground Clearance (in):
    15
  • Dry Weight (lbs):
    1811
  • Towing Capacity (lbs):
    2500
  • Fuel Capacity (gal):
    10.6
  • Engine Displacement to Weight (cc):
    0.54
  • Payload Capacity (lbs):
    1500
  • Storage Capacity (gal):
    16.2
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    12
  • Rear Travel (in):
    12
  • Number Rear Shock Absorbers:
    2
• WHEELS & TIRES

  add remove
  • Front Tire Diameter (in):
    30
  • Rear Tire Diameter (in):
    30
  • Tread Type:
    Knobby
  • Front Tire Width:
    9
  • Front Wheel Diameter:
    14
  • Rear Tire Width:
    11
  • Rear Wheel Diameter:
    14
  • Front Tire (Full Spec):
    XPS Swamp Force 30 x 9-14
  • Rear Tire (Full Spec):
    XPS Swamp Force 30 x 11-14
