Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    6
  • Valves Per Cylinder:
    3
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.11
  • Stroke (in):
    2.99
  • Displacement (cc):
    745
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • US Miles Per Gallon (Combined):
    56
  • Compression Ratio:
    9.6:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    No
  • Gear Ratio (1):
    2.4
  • Gear Ratio (2):
    1.55
  • Gear Ratio (3):
    1.17
  • Gear Ratio (4):
    0.96
  • Gear Ratio (5):
    0.85
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    64.5
  • Fuel Capacity (gal):
    3.9
  • Fuel Capacity Reserve (gal):
    0.9
  • Length (in):
    93
  • Width (in):
    32.6
  • Height (in):
    42.1
  • Ground Clearance (in):
    5.1
  • Wet Weight (lbs):
    553
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    5.5
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    3.5
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Chromed:
    No
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    Dunlop® 120/90 R17 64S
  • Rear Tire (Full Spec):
    Dunlop® 160/80 R15 74S
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    11.7
  • Rear Brake Type:
    Disc
  • Rear Brake Diameter (in):
    10.9
  • Anti-Lock Brakes:
    Standard
