Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.36
  • Stroke (in):
    2.19
  • Displacement (cc):
    157
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • US Miles Per Gallon (Combined):
    134
  • Compression Ratio:
    12.0:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Reverse:
    No
  • Transmission Brand:
    V-Matic™
  • Primary Drive (Engine / Transmission):
    Belt
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    52.1
  • Fuel Capacity (gal):
    2.1
  • Length (in):
    76.8
  • Width (in):
    30
  • Height (in):
    50
  • Ground Clearance (in):
    6.5
  • Wet Weight (lbs):
    294
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Suspension Size (in):
    1.2
  • Front Travel (in):
    5.1
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    4.1
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Brand Name:
    Showa®
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    Federal® FT 297: 110/80-14 53P
  • Rear Tire (Full Spec):
    Federal® FT 297: 130/70-13 57P
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    9.4
  • Rear Brake Type:
    Drum
  • Rear Brake Diameter (in):
    5
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Not Available
